Product Details:
Key Features and Applications
Telescopic Boom Configuration
The SQ10SK3Q features a multi-section telescopic boom that provides a flexible reach and high lifting heights. This design is particularly effective for reaching over obstacles or placing materials at significant heights during construction or facility maintenance.
Precise Hydraulic Control
Equipped with advanced hydraulic systems, this truck mounted crane offers smooth and sensitive control for lifting and slewing. The integrated hydraulic valves ensure steady operation, allowing for the precise positioning of heavy loads in industrial environments.
360-Degree Slewing Angle
The crane is designed with a full 360-degree continuous rotation capability. This unrestricted slewing allows operators to load and unload materials from any direction without needing to reposition the vehicle, significantly increasing operational efficiency.
Versatile Cargo Applications
Designed for heavy-duty utility, this crane is suitable for:
-
Logistics and Transport: Efficient loading and delivery of palletized goods and construction materials.
-
Municipal Engineering: Supporting road repairs, lighting maintenance, and greening projects.
-
Construction Sites: Lifting and moving structural components and equipment across job sites.
Technical Specifications
| Item | Unit | Parameter |
| Max. Lifting Capacity | kg | 10,000 |
| Max. Lifting Moment | t.m | 25 |
| Max. Working Radius | m | 12.0 |
| Max. Lifting Height | m | 14.0 |
| Recommended Power | kW | 28 |
| Max. Oil Flow of Hydraulic System | L/min | 63 |
| Rated Pressure of Hydraulic System | MPa | 26 |
| Crane Weight | kg | 3,800 |
| Installation Space | mm | 1,150 |
| Rotation Angle | ° | 360 (Continuous) |
Dimensions and Operating Range
The SQ10SK3Q provides a maximum working radius of 12 meters and a lifting height of 14 meters. The compact installation space of 1,150 mm ensures it can be mounted on various standard heavy-duty truck chassis while preserving sufficient space for the cargo bed. Its telescopic reach is managed via multi-stage booms that extend predictably under load.
Supplier Support
We provide technical and purchasing support for the SQ10SK3Q truck mounted crane. Our supply capabilities include the availability of relevant spare parts to support long-term maintenance and operational uptime. We assist international procurement clients with detailed specifications, quotations, and logistical coordination for global equipment delivery.
Frequently Asked Questions
What is the maximum lifting capacity of the SQ10SK3Q?
The SQ10SK3Q has a maximum rated lifting capacity of 10,000 kg (10 tons) at its minimum radius.
What chassis is compatible with this 10-ton crane?
The SQ10SK3Q is designed for mounting on standard heavy-duty truck chassis. Please contact our technical team to confirm specific chassis compatibility and installation requirements.
Can the SQ10SK3Q rotate continuously?
Yes, this model features a 360-degree continuous slewing mechanism, allowing for full rotational movement during lifting operations.
What industries is this truck mounted crane best suited for?
It is widely used in construction, municipal maintenance, logistics, and power facility repairs due to its combined lifting and transportation capabilities.
