Product Details:
Key Features and Applications
Compact Maneuverability for Narrow Sites
The LW200KV features an articulated steering design and a compact wheelbase, allowing for a tight turning radius. This agility is essential for navigating narrow urban streets, indoor warehouse facilities, and crowded freight yards where traditional large loaders cannot operate effectively.
Reliable Power and Drivetrain
Equipped with a high-torque 58kW engine and a synchronized hydraulic system, the loader provides steady traction and breakout force. The powertrain is calibrated to balance fuel consumption with the strength required for penetrating soil or aggregate piles, ensuring productive work cycles.
Durable Structural Build
The machine is constructed using high-strength steel for the frames and working devices. The reinforced boom and bucket linkage are engineered to withstand the stresses of high-frequency loading, providing a long service life in demanding industrial and construction settings.
Ergonomic Operator Environment
The cab is designed with human-machine ergonomics as a priority, offering a wide field of vision and intuitive control layouts. Improved noise reduction and optimized ventilation ensure a productive and stable environment for operators during long shifts in diverse climates.
Simplified Ground-Level Maintenance
Following a user-centric design philosophy, the LW200KV offers easy access to the engine compartment and major maintenance points from the ground. This accessibility simplifies routine daily checks and reduces machine downtime, supporting higher equipment utilization for fleet owners.
Technical Specifications
| Item | Unit | Parameter |
| Rated Operating Load | kg | 2000 |
| Machine Operating Weight | kg | 6300 |
| Bucket Capacity | m³ | 1.1 |
| Dump Clearance (at max. lift) | mm | 2800 |
| Reach at Max. Lift | mm | 900 |
| Wheelbase | mm | 2300 |
| Engine Rated Power | kW | 58 |
| Rated Engine Speed | rpm | 2400 |
| Max. Travel Speed | km/h | 26 |
| Max. Breakout Force | kN | 55 |
Dimensions and Operating Range
The XCMG LW200KV is designed with an overall length and width optimized for standard transport and site accessibility. With a maximum dumping height of 2800 mm, it can effectively load small-to-medium trucks and hoppers. The articulated steering ensure the machine can pivot efficiently in high-density job sites while maintaining stability through a balanced wheelbase and tread width.
Supplier Support
We provide professional technical documentation and procurement support for the XCMG LW200KV wheel loader. Our services include the provision of detailed technical specifications and assistance with logistical coordination for international delivery. To ensure long-term operational uptime, relevant maintenance parts and spare components for this model are available through our supply network.
Frequently Asked Questions
What is the rated lifting capacity of the XCMG LW200KV?
The LW200KV has a rated operating load capacity of 2000 kg, which is equivalent to 2 tons.
Is the LW200KV suitable for narrow work sites?
Yes, its compact dimensions and articulated steering make it specifically designed for confined areas such as urban streets, indoor yards, and small-scale construction zones.
What type of engine powers the LW200KV?
The machine is equipped with a high-torque engine providing a rated power of 58 kW, optimized for balancing fuel efficiency with the breakout force required for loading tasks.
What is the standard bucket capacity for this model?
The standard bucket capacity for the XCMG LW200KV is 1.1 m³, providing a balanced load volume for its weight class.
