Product Details:
Key Features and Applications
Reinforced Structural Integrity
The LW1000KN features a super-strong structural build, incorporating reinforced front and rear frames with a heavy-duty box-type structure. This design is engineered to withstand high torsional stress and the heavy impact loads typical of mining and quarrying environments, ensuring a stable platform for long-term loading operations.
High-Efficiency Power and Drive
Equipped with a high-torque 280 kW engine and specialized transmission, the loader provides consistent traction and breakout force. The powertrain is optimized to balance fuel economy with the strength required for penetrating tough materials, increasing overall site productivity.
Advanced Hydraulic and Working Device
The machine utilizes an optimized linkage system that maximizes breakout force and improves bucket retention. The high-capacity hydraulic system enables a total work cycle time of approximately 11.5 seconds, significantly increasing site productivity during truck-loading and stockpiling operations.
Comfortable Operator Environment
The full-view cab is designed with human-machine ergonomics as a priority. It provides the operator with maximum visibility, reduced noise levels, and intuitive control layouts. These features are essential for maintaining safety and productivity during long shifts in demanding industrial settings.
Simplified Maintenance Design
Following the concept of easy accessibility, the machine is designed with centrally located lubrication points and ground-accessible maintenance components. This layout allows for routine checks and daily servicing to be performed efficiently, reducing machine downtime and improving fleet utilization.
Technical Specifications
| Item | Unit | Parameter |
| Rated Operating Load | kg | 10,000 |
| Bucket Capacity | m³ | 5.0 – 6.0 |
| Machine Operating Weight | kg | 35,000 |
| Dump Clearance (at max. lift) | mm | 3,450 |
| Reach at Max. Lift | mm | 1,480 |
| Wheelbase | mm | 3,750 |
| Engine Rated Power | kW | 280 |
| Rated Engine Speed | rpm | 2,100 |
| Maximum Traction Force | kN | 300 |
| Maximum Breakout Force | kN | 310 |
| Total Cycle Time | s | 11.5 |
Dimensions and Operating Range
The XCMG LW1000KN features a wheelbase of 3,750 mm, providing a stable center of gravity during full-load maneuvers. With a standard dumping height of 3,450 mm, it is capable of loading high-sided mining trucks and industrial hoppers effectively. The articulated steering system provides the maneuverability required for large logistics yards and construction sites, while its overall dimensions are calibrated for standard transport and site accessibility.
Supplier Support
We provide professional procurement and technical support for the XCMG LW1000KN wheel loader. Our services include assistance with equipment configuration consulting and logistical coordination for international delivery. All relevant maintenance parts and spare components for this model are available through our supply network to support the long-term operational uptime of your equipment.
Frequently Asked Questions
What is the maximum rated load of the XCMG LW1000KN?
The XCMG LW1000KN has a rated operating load capacity of 10,000 kg (10 tons).
What are the standard bucket options for this loader?
The bucket capacity ranges from 5.0 m³ to 6.0 m³, which can be selected based on the specific material density and application requirements, such as coal, aggregate, or minerals.
Is the LW1000KN suitable for open-pit mining?
Yes, due to its reinforced box-frame structure and high breakout force (310 kN), the LW1000KN is specifically designed to perform reliably in mining and quarrying environments.
What engine is equipped in this model?
The LW1000KN is equipped with a 280 kW engine optimized for high torque and reliability in heavy-duty industrial construction and earthmoving tasks.
What is the dumping height for the LW1000KN?
This loader provides a dumping clearance of 3,450 mm at maximum lift, making it compatible with large-capacity transport vehicles.
