Product Details:
Key Features and Applications
High Breakout Force and Traction
The LW600FN is designed for heavy-duty penetration, delivering a breakout force of ≥205kN and a traction force of ≥174kN. These performance metrics allow the loader to handle tough materials and maintain high productivity during intensive stockpiling and truck-loading cycles.
Proven Powertrain Reliability
Equipped with a three-element torque converter and a fixed shaft power shift transmission, the machine offers high maturity and stability. This configuration ensures smooth power delivery and reliable operation across various working conditions, minimizing downtime for maintenance.
Structural Stability and Maneuverability
Featuring a long wheelbase of 3350mm, the machine provides superior stability during high-load operations. Despite its size, it maintains a turning radius of 6005mm (at tire center), offering the flexibility required for navigating busy job sites and industrial facilities.
Durable Bucket Design
The bucket is constructed from high-strength, wear-resistant materials, specifically optimized for high impact resistance. This structural reinforcement ensures a longer service life for the working tools when handling abrasive or heavy materials.
Versatile Industrial Utility
The LW600FN is a multipurpose asset suitable for several sectors:
-
Ports and Logistics: Efficient bulk material handling and ship loading.
-
Mining and Quarrying: Heavy aggregate transport and loading.
-
Large-scale Infrastructure: Road construction, site grading, and earthmoving.
Technical Specifications
| Item | Unit | Parameter |
| Rated operating load | kg | 6000 |
| Bucket capacity | m³ | 3.0 ~ 4.5 |
| Machine weight | kg | 20000 ± 300 |
| Dump clearance at maximum lift | mm | 2970 ~ 3530 |
| Reach at maximum lift | mm | 1200 ~ 1360 |
| Wheelbase | mm | 3350 |
| Overall machine dimension (L×W×H) | mm | 8350 × 3040 × 3505 |
| Tread | mm | 2250 |
| Rated Power / Speed | kW / rpm | 178 / 2200 |
| Traction Force | kN | ≥ 174 |
| Breakout Force | kN | ≥ 205 |
| Turning Radius (tire center) | mm | 6005 |
Dimensions and Operating Range
The XCMG LW600FN features a total length of 8350 mm and a width of 3040 mm, providing a stable footprint for 6-ton loading operations. Its dump clearance at maximum lift ranges between 2970mm and 3530mm, enabling it to load high-sided trucks and industrial hoppers. The reach of up to 1360mm ensures precision during material placement and reduces maneuvering time during loading cycles.
Supplier Support
We provide technical documentation and procurement support for the XCMG LW600FN wheel loader. Our services assist international buyers with equipment configuration and logistical coordination. For detailed purchasing information and specialized technical support, please consult our sales team.
Frequently Asked Questions
What is the rated load capacity of the XCMG LW600FN?
The XCMG LW600FN has a rated operating load of 6000 kg (6 tons).
What is the standard engine power for this model?
This wheel loader is equipped with an engine providing a rated power of 178 kW at 2200 rpm.
Can the bucket size be adjusted for different materials?
Yes, the bucket capacity ranges from 3.0 m³ to 4.5 m³, allowing for adjustments based on the density of the material being handled.
What are the main applications for a 6-ton loader?
This model is ideal for heavy-duty tasks in mining, port logistics, and large construction projects that require high breakout force and large material volumes.
