Product Details:
Key Features and Applications
High Breakout Force and Traction
The LW600KN is designed for superior penetration and loading efficiency. With a breakout force of 205 kN and high traction capabilities, the loader effectively handles tough materials and hard stockpiles, ensuring productive cycle times in challenging site conditions.
Reinforced Structural Design
The machine features a super-strong structural build, incorporating a long wheelbase and high-strength frames. This design ensures excellent stability during heavy-lift operations and improves the equipment’s resistance to torsional stress in mining and quarrying environments.
Energy Efficiency and Power
Equipped with a 178 kW engine and an optimized hydraulic system, the LW600KN focuses on fuel economy without compromising on power. The powertrain is calibrated to provide high torque at low speeds, reducing operational costs during high-frequency duty cycles.
Optimized Operating Environment
The full-view cab is designed with human-machine ergonomics to improve operator comfort and safety. It provides a wide field of vision, reduced noise levels, and intuitive control layouts, which are essential for maintaining productivity during long shifts.
Versatile Industrial Utility
This 6-ton loader is suitable for a wide range of applications:
-
Infrastructure: Bulk material handling and site grading.
-
Ports & Logistics: Efficient loading and unloading of transport vehicles and ships.
-
Mining & Quarrying: Loading heavy minerals, rocks, and aggregate handling.
Technical Specifications
| Item | Unit | Parameter |
| Rated Operating Load | kg | 6000 |
| Bucket Capacity | m³ | 3.0 – 5.0 |
| Machine Operating Weight | kg | 20000 |
| Dump Clearance at Maximum Lift | mm | 3010 – 3500 |
| Reach at Maximum Lift | mm | 1200 – 1300 |
| Wheelbase | mm | 3350 |
| Overall Machine Dimensions (L×W×H) | mm | 8350 × 3040 × 3505 |
| Engine Rated Power | kW | 178 |
| Max. Travel Speed | km/h | 38 |
| Breakout Force | kN | 205 |
| Traction Force | kN | 174 |
Dimensions and Operating Range
The XCMG LW600KN features a total length of approximately 8350 mm and a width of 3040 mm, providing a stable footprint for 6-ton loading cycles. Its dumping clearance at maximum lift reaches up to 3500 mm (depending on configuration), allowing the machine to load standard high-sided trucks and industrial hoppers efficiently. The wheelbase of 3350 mm is specifically chosen to distribute the center of gravity for maximum balance during full-bucket maneuvers.
Supplier Support
We provide professional procurement and technical support for the XCMG LW600KN wheel loader. Our services include the provision of detailed technical documentation and assistance with the availability of relevant spare parts to support long-term maintenance. We assist international buyers with logistical coordination to ensure efficient equipment delivery to project sites worldwide.
Frequently Asked Questions
What is the standard bucket capacity of the XCMG LW600KN?
The standard bucket capacity is 3.5 m³, though it can be configured from 3.0 m³ to 5.0 m³ to suit different material densities such as coal, rock, or soil.
What are the primary applications for this 6-ton loader?
The LW600KN is widely used in heavy-duty sectors including mining, port logistics, aggregate yards, and large-scale civil engineering projects.
Is the LW600KN optimized for fuel efficiency?
Yes, it features a specialized powertrain and hydraulic system designed to reduce fuel consumption while maintaining high breakout force and traction for industrial tasks.
What is the maximum travel speed of the XCMG LW600KN?
The loader can reach a maximum forward travel speed of 38 km/h, facilitating rapid relocation within the job site.
