Product Details:
Key Features and Applications
High-Performance Power System
The LW700KV is equipped with a high-torque 226kW engine that provides consistent power for heavy-lift cycles. The powertrain is optimized for energy conservation, ensuring that the machine delivers high traction (190kN) while managing fuel consumption during intensive work shifts in mining or aggregate yards.
Reinforced Structural Integrity
The front and rear frames are designed with a heavy-duty box structure to withstand torsional stress and impact loads. This structural durability is paired with a long 3,400mm wheelbase to ensure excellent stability when the machine is navigating rugged terrain with a full bucket.
Optimized Hydraulic and Working Device
Utilizing a Z-bar linkage system, the loader achieves a maximum breakout force of 210kN. The hydraulic system is calibrated for smooth transitions and fast cycle times (total cycle time < 11.5s), which significantly increases productivity during stockpiling and truck-loading operations.
Comfortable and Safe Operating Environment
The cab is designed with human-machine ergonomics in mind, offering a wide field of vision and noise reduction features. The layout of the controls and monitoring systems assists operators in maintaining precision and safety throughout high-frequency material handling tasks.
Simplified Maintenance Access
The machine incorporates a design that facilitates easy daily servicing. All critical pressure measurement points and grease nipples are arranged for convenient access from the ground level, helping to reduce machine downtime and improve overall fleet utilization.
Technical Specifications
| Item | Unit | Parameter |
| Rated Operating Load | kg | 7,000 |
| Bucket Capacity | m³ | 4.2 (3.5 ~ 6.0) |
| Machine Operating Weight | kg | 23,500 ± 300 |
| Dump Clearance (at max. lift) | mm | 3,200 |
| Reach at Max. Lift | mm | 1,200 |
| Wheelbase | mm | 3,400 |
| Overall Machine Dimensions (L×W×H) | mm | 9,100 × 3,230 × 3,515 |
| Engine Rated Power | kW | 226 |
| Maximum Traction Force | kN | 190 |
| Maximum Breakout Force | kN | 210 |
| Total Cycle Time | s | < 11.5 |
Dimensions and Operating Range
The XCMG LW700KV features a stable footprint with a total length of 9,100 mm and a width of 3,230 mm. With a dump clearance of 3,200 mm, it is highly effective for loading high-sided transport vehicles and industrial hoppers. The turning radius (tire center) is 6,400 mm, allowing for efficient maneuvering in ports, logistics terminals, and open-pit mining sites.
Supplier Support
We provide comprehensive technical documentation and procurement support for the XCMG LW700KV wheel loader. Our services include assistance with configuration consulting for international project requirements. All relevant maintenance parts and spare components for the LW700KV are available through our supply network to support the long-term uptime of your equipment.
Frequently Asked Questions
What is the maximum bucket capacity for the XCMG LW700KV?
While the standard bucket is 4.2 m³, the machine can be configured with buckets ranging from 3.5 m³ to 6.0 m³ to suit different material densities, such as rock, soil, or coal.
Is the LW700KV suitable for mining operations?
Yes, the LW700KV is specifically engineered for heavy-duty applications including mining and quarrying, thanks to its high breakout force and reinforced structural frames.
What engine powers this 7-ton loader?
The machine is equipped with a 226 kW engine designed for high torque and reliability in industrial construction and earthmoving tasks.
What is the total machine weight?
The operating weight of the LW700KV is approximately 23,500 kg, providing the necessary ballast for stable 7-ton lifting operations.
