Product Details:
Key Features and Applications
High-Output Cummins Power Unit
Equipped with a 6-cylinder, 15-liter Cummins QSX15 turbocharged diesel engine, the machine delivers a rated power output of 336 kW and a maximum torque of 2,102 N.m at 1,400 rpm. The integrated high-pressure fuel injection system utilizes electronic ECM management to govern fuel volume and timing precisely, maintaining responsive hydraulic power while optimizing fuel consumption under high-load continuous cycles.
Advanced Negative Flow Hydraulic System
The hydraulic architecture incorporates dual main plunger pumps with a combined displacement of 2 × 450 L/min and an upgraded main control valve featuring regeneration, convergence, and priority functions. An independent hydraulic oil cooling circuit with an automated, reversible fan regulates operating temperature based on real-time oil conditions and reverses rotation to clear dust and debris from cooling cores.
Heavy-Duty Intake and Fuel Filtration
Designed for dusty quarry and mining environments, the XE700D uses a multi-stage air intake system with high-efficiency filtration alongside a three-stage fuel filtering system (one coarse filter and two fine filters). A visual oil-water separator allows operators to inspect fuel conditions easily, protecting high-pressure fuel components from water and particulate contamination.
Reinforced Mining-Grade Undercarriage
The upper turntable employs an I-beam structure welded from high-strength steel plates, flanked by D-section side skirts to resist lateral impacts. The lower undercarriage features heavy-duty track rollers, reinforced full-length track guides, Dacromet-coated fasteners, and cast steel components in key stress areas of the boom and arm to withstand severe torsional and shock loads.
Primary Application Sectors
-
Open-Pit Mining: Bulk overburden stripping, ore excavation, and heavy haul truck loading.
-
Quarries and Aggregates: Primary blasted rock handling, crushing plant feeding, and heavy stockpiling.
-
Large Infrastructure: Bulk cut-and-fill operations, dam construction, and major earthworks.
Technical Specifications
| Item | Unit | Parameter |
| Operating Weight | kg | 69,000 |
| Bucket Capacity Range | m³ | 2.4 – 4.6 |
| Engine Model | – | Cummins QSX15 |
| Number of Cylinders | – | 6 |
| Engine Displacement | L | 15.0 |
| Rated Power / Speed | kW / rpm | 336 / 1,800 |
| Maximum Torque / Speed | N.m / rpm | 2,102 / 1,400 |
| Bucket Digging Force | kN | 363 |
| Arm Digging Force | kN | 300 |
| Maximum Tractive Force | kN | 450 |
| Main Hydraulic Pump Type | – | 2 × Variable Piston Pumps |
| Main Pump Rated Flow | L/min | 2 × 450 |
| Main Safety Valve Pressure | MPa | 31.4 / 34.3 |
| Travel Circuit Pressure | MPa | 34.3 |
| Travel Speed (High / Low) | km/h | 4.2 / 3.0 |
| Swing Speed | r/min | 7.0 |
| Gradeability | ° | 35 |
| Ground Contact Pressure | kPa | 101.4 |
Dimensions and Operating Range
| Item | Unit | Parameter |
| Maximum Digging Height | mm | 11,350 |
| Maximum Dumping Height | mm | 7,370 |
| Maximum Digging Reach | mm | 11,580 |
| Ground Contact Length | mm | 4,700 |
| Track Gauge | mm | 3,300 |
| Counterweight Ground Clearance | mm | 1,510 |
Supplier Support
We provide technical documentation and procurement support for the XCMG XE700D crawler mining excavator. Our team assists international buyers with machine configuration, attachments, export documentation, and global shipping logistics. To support long-term machine availability and minimize jobsite downtime, genuine maintenance filters, wear parts, and hydraulic replacement components are accessible through our supply network.
Frequently Asked Questions
What engine is equipped in the XCMG XE700D excavator?
The XE700D is powered by a 6-cylinder Cummins QSX15 turbocharged, intercooled diesel engine with a 15-liter displacement, producing 336 kW at 1,800 rpm and 2,102 N.m of torque at 1,400 rpm.
What bucket options can be configured on the XE700D?
The excavator accommodates bucket capacities ranging from 2.4 m³ to 4.6 m³, allowing configurations to match material density, such as heavy rock buckets for quarrying or larger capacity buckets for loose overburden.
How does the XE700D handle high-dust mining environments?
The machine integrates a multi-stage heavy-duty air filter system alongside a three-stage fuel filtration system with a visual oil-water separator, shielding critical engine components from particulate ingress.
What are the main features of the hydraulic cooling system?
The hydraulic system uses an independent cooling circuit with an automatically controlled fan that adjusts speed based on fluid temperature. The fan also features a reverse rotation function to blow out accumulated dust and debris from the cooling package.
