Product Details:
Key Features and Applications
Cummins Power Unit and Efficient Drivetrain
The machine is equipped with a Cummins 6BTA5.9 diesel engine delivering consistent torque output and low fuel consumption. Coupled with an electro-hydraulic power shift gearbox offering 6 forward and 3 reverse speeds, operators can match torque and travel speed smoothly to job requirements without shift disruption.
Articulated Frame and High Maneuverability
Featuring front-wheel steering combined with an articulated frame structure, the GR135 achieves a tight turning radius. This configuration allows operators to navigate confined worksites, sharp curves on rural roads, and restricted urban job sites with high mobility.
Heavy-Duty Rear Axle with Self-Locking Differential
The three-stage rear drive axle incorporates a self-locking differential mechanism. When one wheel encounters soft ground or loses traction, torque transfers evenly across the drive axle, maintaining steady tractive effort during heavy blade passes and ditching operations.
Fully Hydraulic Blade System
The working moldboard is controlled entirely via precision hydraulic circuits using international supporting hydraulic components. It provides fast response, stable blade holding, and smooth positioning for precision land leveling, bank sloping, and trench backfilling.
Ergonomic Operator Station
The cab interior is designed for operational safety and reduced fatigue. It features an adjustable operating console, ergonomic seating, and strategically positioned joysticks and gauges, ensuring clear line of sight to both the moldboard and working direction.
Technical Specifications
| Parameter | Specification |
| Machine Model | GR135 |
| Equipment Type | Motor Grader |
| Engine Model | Cummins 6BTA5.9 |
| Rated Power / Speed | 97–112 kW (135 HP) @ 2,200 rpm |
| Operating Weight | 11,200 kg |
| Transmission Type | Electro-hydraulic power shift |
| Gear Speeds | 6 Forward / 3 Reverse |
| Maximum Forward Speed | 42 km/h |
| Drive Axle Type | Three-stage drive axle |
| Differential System | Rear axle with self-locking differential |
| Steering Method | Front-wheel steering + Articulated frame |
| Hydraulic System Control | Full hydraulic blade control |
| Maximum Blade Lift Height | 410 mm |
| Maximum Cutting Depth | 515 mm |
Dimensions and Operating Range
| Working Range Parameter | Value |
| Maximum Blade Lift Above Ground | 410 mm |
| Maximum Blade Cutting Depth | 515 mm |
| Maximum Travel Speed (Forward) | Up to 42 km/h |
| Steering Configuration | Articulated frame with front-wheel assist |
Supplier Support and Procurement Services
-
Genuine Spare Parts Supply: Complete spare parts packages for the GR135 motor grader are available to support routine maintenance and repairs.
-
Equipment Supply Options: Supply capabilities include brand-new units as well as verified second-hand machinery options depending on project budgets.
-
Commercial Export Handling: Full assistance with commercial invoicing, technical documentation, export crating, and international shipping logistics.
Frequently Asked Questions
What engine is installed in the GR135 motor grader?
The GR135 is powered by a Cummins 6BTA5.9 diesel engine delivering a rated output between 97 kW and 112 kW (135 HP) at 2,200 rpm.
What transmission configuration does this machine use?
The grader utilizes an electro-hydraulic control power shift transmission with 6 forward speeds and 3 reverse speeds, delivering forward speeds up to 42 km/h.
What are the primary earthwork tasks suitable for the GR135?
The GR135 is configured for large-scale ground leveling, ditching, slope scraping, bulldozing, soil scarification, and snow clearing in urban road construction, highway subgrades, mining haul paths, airport grounds, and agricultural improvement sites.
Are replacement parts available for the GR135?
Yes. All structural, mechanical, and hydraulic spare parts corresponding to the GR135 motor grader are supplied for international procurement and fleet upkeep.
