Product Details:
Key Features and Applications
Compact Body with Flexible Width Adjustment
Featuring an overall fuselage width of 2.0 meters and a length of 5.8 meters, the RP505 easily navigates urban communities, alleys, and tight roadways. With the optional width-limiting device installed, the minimum paving width can be reduced to 0.8 meters, making it suitable for the paving and maintenance of milling grooves and utility cuts.
Full Hydraulic Independent Crawler Drive
The machine utilizes an all-hydraulic independent drive system with crawler tracks that provide strong tractive effort. Equipped with 260mm wide split crawler shoes, it offers a large ground contact area and high adhesion, allowing it to adapt smoothly to push-feeding operations from various dump truck configurations.
Load-Sensitive Hydraulic Control
The hydraulic system adopts load-sensitive control technology that distributes power dynamically according to the operational load of each functional circuit. This ensures that hydraulic output is efficient and stable while minimizing energy loss and fuel consumption during continuous paving cycles.
High-Capacity Material Hopper
Equipped with a 12-ton capacity hopper and a maximum theoretical laydown rate of 400 t/h, the RP505 accommodates continuous material delivery from transport trucks, reducing stop-and-go occurrences and supporting steady mat laydown.
Primary Municipal and Highway Applications
-
Urban Infrastructure: Street paving, auxiliary lanes, sidewalks, and non-motorized vehicle paths.
-
Road Maintenance: Classified highway resurfacing, shoulder repairs, and asphalt milling groove reinstatement.
-
Restricted Environments: Community roads, agricultural lanes, and utility trench backfilling.
Technical Specifications
| Item | Unit | Parameter |
| Model | – | RP505 |
| Total Weight | t | 12.5 |
| Basic Paving Width | m | 1.8 – 3.4 |
| Maximum Paving Width | m | 5.0 |
| Minimum Paving Width (with Cut-offs) | m | 0.8 |
| Maximum Paving Thickness | mm | 280 |
| Theoretical Productivity | t/h | 400 |
| Hopper Capacity | t | 12 |
| Engine Rated Power | kW | 86 |
| Crawler Shoe Width | mm | 260 |
| Overall Dimensions (L×W×H) | mm | 5820 × 2000 × 3690 |
Dimensions and Operating Range
The XCMG RP505 features overall machine dimensions of 5,820 mm in length, 2,000 mm in width, and 3,690 mm in height. Its basic working width spans 1.8 to 3.4 meters, extending up to a maximum width of 5.0 meters with mechanical extensions, and reducing down to 0.8 meters using cut-off shoes for trench work. With a maximum layer thickness capability of 280 mm, it accommodates both deep structural base courses and thin surface layers.
Supplier Support
All relevant spare parts for the XCMG RP505 small road asphalt paver are available through our supply network to support long-term maintenance and operational uptime. We provide technical documentation, configuration consulting, and export procurement support. Our team coordinates international shipping logistics to ensure equipment arrives ready for project deployment.
Frequently Asked Questions
What is the minimum and maximum paving width of the XCMG RP505?
The RP505 has a basic extendable paving width of 1.8 to 3.4 meters, scaling up to a maximum of 5.0 meters with extensions. With the optional width-limiting reduction cut-offs installed, it can pave widths as narrow as 0.8 meters.
What engine power is equipped on the RP505 paver?
The machine is powered by an 86 kW industrial diesel engine that drives a load-sensitive hydraulic system for balanced output and fuel economy.
Can the RP505 pave narrow trenches and milling grooves?
Yes. With the width-limiting device fitted, the paving width reduces to 0.8 meters, making it suitable for backfilling and paving road cuts, pipeline trenches, and asphalt milling grooves.
Are spare parts available for this model?
Yes, all relevant spare parts and replacement wear components for the XCMG RP505 small asphalt paver are accessible through our supply network.
